Pylon · Jasper Active · Floorstander

Jasper 23 Active

Product description
The passive Jasper 23 made self-powered: the same 166 mm-wide curved cabinet, twin 15 cm Scan-Speak Revelators and 0.18 g D2608 dome, now with a 150 W Class D module behind each driver (450 W a side) and a DSP crossover in place of the passive network. The amplifier plate sits low on the back, below the two rear reflex tunnels, and carries a single XLR — the only wired input on the speaker, fed balanced or unbalanced. Everything else arrives over WiSA from the optional Stereo Hub, which sends both channels wirelessly at 24-bit/192 kHz and adds HDMI ARC, three optical, coax, USB-B, RCA and minijack inputs plus Chromecast, AirPlay 2, Spotify Connect, Roon Ready and Bluetooth 5.0. Pylon aims it at rooms of 18–35 m². Hand-built in Jarocin, Poland. Sold as a pair; the hub is extra.

Performance — where it sits in the catalog

BassTrebleCone area
Bass reachTreble reachCone area
Jasper 23 Active35 Hz20 kHz359 cm²
Median30 Hz24 kHz692 cm²
How to read this chart

Each axis spans the range the 640 floorstanders in the catalog actually cover, so equal distance means equal difference — and for cone area and the two frequencies, which are read as ratios, equal distance means equal ratio. The dashed inner ring is where the scale starts, not zero. Ranked within a class because a bookshelf measured against floorstanders is feeble on every axis for the single reason that it is a bookshelf. Cone area is summed from the drive units — no maker publishes it. Bass and treble reach are quoted to different tolerances and only 56% of the catalog says which, so read those two axes as approximate. The grey outline is the median of this speaker's own class, the 48 active floorstanders — same type, same side of the active/passive line, which matters because the two halves are not the same product: the median active bookshelf carries 155 cm² of cone against the passive median's 219. Median rather than mean, because a handful of very large cabinets would drag a mean above most of the class it claims to describe. Not shown: Sensitivity, Easy load — the maker publishes no figure. Active speakers quote no sensitivity and no impedance, because with the amplifier inside both describe the electronics rather than the cabinet.

Units
TypeFloorstander
HiFi ladder position#130 of 640 floorstander
PowerActive
Height992 mm
Width166 mm
Depth401 mm
Footprint666 cm²
Space taken66 L
Weight26 kg
EnclosureBass reflex, rear port
Drivers1× 26 mm tweeter (Scan-Speak D2608/913000 silk dome), 2× 150 mm woofer (Scan-Speak 15W/8531K00)
Frequency response35–20000 Hz
MAP (USD)$8,700 / pair
Amplification (per driver)tweeter 150 W (class D) · woofer 150 W (class D)
Total amp power450 W
Max SPL @ 1 m—
Hi-res audio24 bit / 192 kHz
Wired inputsXLR balanced
Streaming / wirelessWiSA
Outputs—
Room correction—
Primary + secondary pairNo
Wireless inter-speaker linkYes
Latency—
Idle power—
Max consumption—
Where to buyCheck availability ↗
Manufacturerpylon.pl ↗
Product pageOpen product page ↗
