Pylon · Jasper Active · Floorstander

Jasper 23 Active

Product description
The passive Jasper 23 made self-powered: the same 166 mm-wide curved cabinet, twin 15 cm Scan-Speak Revelators and 0.18 g D2608 dome, now with a 150 W Class D module behind each driver (450 W a side) and a DSP crossover in place of the passive network. The amplifier plate sits low on the back, below the two rear reflex tunnels, and carries a single XLR — the only wired input on the speaker, fed balanced or unbalanced. Everything else arrives over WiSA from the optional Stereo Hub, which sends both channels wirelessly at 24-bit/192 kHz and adds HDMI ARC, three optical, coax, USB-B, RCA and minijack inputs plus Chromecast, AirPlay 2, Spotify Connect, Roon Ready and Bluetooth 5.0. Pylon aims it at rooms of 18–35 m². Hand-built in Jarocin, Poland. Sold as a pair; the hub is extra.
Units
TypeFloorstander
HiFi ladder position#126 of 598 floorstander
PowerActive
Height992 mm
Width166 mm
Depth401 mm
Weight26 kg
EnclosureBass reflex, rear port
Drivers1× 26 mm tweeter (Scan-Speak D2608/913000 silk dome), 2× 150 mm woofer (Scan-Speak 15W/8531K00)
Frequency response35–20000 Hz
MAP (USD)$8,700 / pair
Amplification (per driver)tweeter 150 W (class D) · woofer 150 W (class D)
Total amp power450 W
Max SPL @ 1 m—
Hi-res audio24 bit / 192 kHz
Wired inputsXLR balanced
Streaming / wirelessWiSA
Outputs—
Room correction—
Primary + secondary pairNo
Wireless inter-speaker linkYes
Latency—
Idle power—
Max consumption—
Where to buyCheck availability ↗
Manufacturerpylon.pl ↗
Product pageOpen product page ↗
