Canton · Reference · Floorstander

Reference 1

Product description
The flagship of Canton's 2023 Reference line — a three-way tower with a 25 mm aluminium-oxide ceramic tweeter, a 174 mm Black Ceramic Tungsten (BCT) midrange and three 219 mm BCT woofers in a down-firing ported cabinet. The largest bass array in the standard Reference range makes it Canton's full-scale statement for a large room, below only the Reference Alpha models.

Performance — where it sits in the catalog

BassTrebleSensitivityEasy loadCone area
Bass reachTreble reachSensitivityEasy loadCone area
Reference 118 Hz40 kHz88 dB4 Ω1373 cm²
Median32 Hz30 kHz90 dB6 Ω654 cm²
How to read this chart

Each axis spans the range the 648 floorstanders in the catalog actually cover, so equal distance means equal difference — and for cone area and the two frequencies, which are read as ratios, equal distance means equal ratio. The dashed inner ring is where the scale starts, not zero. Ranked within a class because a bookshelf measured against floorstanders is feeble on every axis for the single reason that it is a bookshelf. Cone area is summed from the drive units — no maker publishes it. Bass and treble reach are quoted to different tolerances and only 56% of the catalog says which, so read those two axes as approximate. The grey outline is the median of this speaker's own class, the 600 passive floorstanders — same type, same side of the active/passive line, which matters because the two halves are not the same product: the median active bookshelf carries 155 cm² of cone against the passive median's 219. Median rather than mean, because a handful of very large cabinets would drag a mean above most of the class it claims to describe.

Units
TypeFloorstander
HiFi ladder position#547 of 648 floorstander
PowerPassive
Height1330 mm
Width367 mm
Depth630 mm
Footprint2312 cm²
Space taken307.5 L
Weight81 kg
EnclosureBass reflex, down-firing port
Drivers1× 25 mm tweeter (aluminium-oxide ceramic dome), 1× 174 mm midrange (Black Ceramic Tungsten cone), 3× 219 mm woofer (Black Ceramic Tungsten cone)
Crossover frequency170 / 3100 Hz
Frequency response18–40000 Hz (±3 dB)
Sensitivity88 dB
Impedance4 Ω (min 4 Ω)
Power handling450 W
MAP (USD)$25,000 / pair
Where to buyCheck availability ↗
Manufacturercanton.de ↗
Product pageOpen product page ↗
